SNMP Huawei LST7X48SX6S0 - 48 Port 10GBASE - X Interface Card X6S SFP

Product Categories
LonRise Equipment Co. Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

SNMP Huawei LST7X48SX6S0 - 48 Port 10GBASE - X Interface Card X6S SFP

Brand Name : Huawei

Model Number : S5735-L48T4X-A1

Certification : CE

Place of Origin : China

Type : Enterprise Switch

Power Supply : AC Power Supply

Description : 48-Port 10GE SFP+ interface card (X6S,SFP+)

Function : LACP, QoS, SNMP, VLAN Support

Warranty : 1 Year

Condition : new

Contact Now

Huawei LST7X48SX6S0 - 48 - Port 10GBASE - X Interface Card (X6S SFP + )

Product Description

S5735-L48T4X-A1 Overview:

S5735-L48T4X-A is the Huawei S5735-L switch with 48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports. Huawei CloudEngine S5735-L is
a series of simplified gigabit access switches that provide 12–48 flexible all-GE downlink ports and four fixed GE or 10 GE uplink
ports. They are designed for enterprise campus network access and gigabit to the desktop. Built on next-generation,
high-performance hardware and powered by Huawei’s Versatile Routing Platform (VRP), CloudEngine S5735-L switches feature flexible
Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols — providing higher
performance and more powerful service processing capabilities for networks.
Quick Spec
Table 1 shows the quick spec.
Product Model
S5735-L48T4X-A
Forwarding Performance
132 Mpps
Switching Capacity2
176 Gbit/s/432 Gbit/s
Fixed Ports
48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports
PoE+
Not supported

Supported Transceivers:

Model
Description
OMXD30000
Huawei Optical Transceiver OMXD30000, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC)
SFP-GE-LX-SM1310
Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC)
OMXD30009
Transceiver, QSFP+, 1310nm, 41.25Gbps, -7dBm, 2.3dBm, -11.5dBm, LC, SMF, 10
ESFP-GE-SX-MM850
Optical Transceiver, eSFP, GE, Multi-mode Module (850nm,0.5km, LC)

S5735-L48T4X-A:

Table specification: S5735-L48T4X-A Specification
Forwarding Performance
132 Mpps
Switching Capacity2
176 Gbit/s/432 Gbit/s
Fixed Ports
48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports
PoE+
Not supported
MAC Features
MAC address auto-learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
Interface-based MAC address learning limiting
VLAN Features
4094 VLANs
Guest VLAN, Voice VLAN
GVRP
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
1:1 and N:1 VLAN mapping
IP Routing
Static route, RIP, RIPng, OSPF, OSPFv3
Super Virtual Fabric (SVF)
Plug-and-play SVF clients
Automatic software package and patch loading to SVF clients
One-click and automatic delivery of service configurations
Independent SVF client operations
Interoperability
VBST (compatible with PVST/PVST+/RPVST)
LNP (similar to DTP)
VCMP (similar to VTP)
